YOKOGAWA CENTUM CS 3000 User Manual

3. Cabling
3-118
TI 33J01J10-01EN
lCabling for AFV30, A2FV50, A2FV70 System
F030906.ai
Cabinet support
Use a cable fastener to fix cables onto the support.
Cable fastener
Figure Cabling Diagram for the AFV30, A2FV50, A2FV70 System
lCabling for L2SW/L3SW
F030907.ai
Cabinet Support
Cable fastenerCable Support
Fix cables to cable support by using cable fastener so that their
connectors are not exposed to undue stress.
Figure Vnet/IP Cabling Diagram for the L2SW/L3SW
Oct. 5, 2018-00
