3. Cabling

3-34

TI 33J01J10-01EN

F030416.ai

General-purpose Cabinet

Insulating bushing

3 units spacing

between devices (*1)

Isolated

AFV30

Node Unit

AEP7D

Protective ground

terminal

Grounding bar

Cabinet ground

Functional grounding

terminal

Ground bus inlet

Protective grounding system

Insulating sheet

Power

 

Figure 19-inch Rack-mount Devices and Wiring

Oct.5, 2018-00
