2. Transportation, Storage and Installation
2-5
TI 33Q01J10-01E
Carrying when Headroom is Low
The cabinet should be carried upright. If this is impossible due to low headroom,
• Remove the side boards.
• Turn the cabinet’s right or left side (viewed from its front) down.
• Gently carry the cabinet with the side down.
• Turn the cabinet to its upright position as soon as the cabinet passes through a place with
low headroom. Attach the side boards to the cabinet.
Using Rollers
The cabinet should be carried in to or near the installation location without unpacking. Do not use
rollers if possible. When using them, take the following precautions:
• Use wooden rollers which are long enough so that more than 200 mm remains outside of
the cabinet on each side.
• Make sure that two or more rollers are always under the cabinet.
• Do not use a hammer to correct roller positions on the move.
Nov. 1, 1998-00
