3. Cabling
3-2
TI 33J01J10-01EN
3.1 Cables and Terminals
Itisrecommendedthatyouuseexible,thin,easy-to-bend,twisted-paircablesto
connect the terminals of the system equipment. Use solderless (crimp-on) terminals with
insulating cover, which have low contact resistance little aging.
Rigidcablesmakecablingworkdicultandexertunnecessaryforceontheterminals,
which may result in system failures.
Cables with the temperature rating of an ambient temperature plus 10 °C or more must be
used.
As for the following models, cables with the temperature rating as shown in the below
Table must be used.
Table Rating temperature of Cables
Models Cables Temperature rating of Cables
ARS15M, ARS55M Signal Cables An ambient temperature plus 20 °C or more
Input Power Cables An ambient temperature plus 30 °C or more
AEP7D (24 VDC) Input Power Cables An ambient temperature plus 50 °C or more
Input Power Cables An ambient temperature plus 30 °C or more
AEPV7D (24 VDC) Input Power Cables An ambient temperature plus 40 °C or more
AEP9D Input Power Cables An ambient temperature plus 60 °C or more
An ambient temperature plus 30 °C or more
A2BN3D
Grounding Cables
An ambient temperature plus 30 °C or more
A2BN3D An ambient temperature plus 20 °C or more
A2BN4D An ambient temperature plus 20 °C or more
A2BN5D
Grounding Cables
An ambient temperature plus 20 °C or more
A2BM4 Terminal board An ambient temperature plus 20 °C or more
n Signal Cables
Nominal conductor cross-sectional area:
2
2
Example of Suitable Cables:
n Alarm and Control Circuit Cables
Nominal conductor cross-sectional area:
Node Inerface Unit External Alarm input terminal:
0.13 to 2.5 mm
2
2
Example of Suitable Cables:
Oct. 5, 2018-00
To Next Page
