n Power Distribution Boards

and DC power distribution boards.
lAC Power Distribution Board
The power cables is branched to each unit by way of a circuit breaker.
Each power system uses three terminals (AC and ground: ISO M4 to M6 screws).
Unit
Unit
Unit
Power distribution board
100-120 V AC or
220-240 V AC
F030206.ai
Figure AC Power Distribution Board
l24 V DC Power Distribution Board
Unit
Unit
Unit
Power distribution board
100-120 V AC or
220-240 V AC
F030207.ai
Figure 24 V DC Power Distribution Board
