TI 33Q01J10-01E
Sep.2008/12th Edition
Safety Precautions
Wiring I/O Cables [Changed the number CSA 1010 to CSA 61010]
1.1 Control Room Design
Side-by-Side Cabinet Installation [Revised the description]
1.2 Control Room Environment
Electric field strength (Electric ware condition) [Title changed and revised the description]
Safety Standards [Changed the CSA C22.2 number 1010.1 to 610101-04]
EMC Conformity Standards [Changed the AS/NZS number 2064 to CISPR 11]
Standards for Hazardous Location Equipment [Revised the description] [Changed EN and IEC
number of Type n]
Installation Environment Specifications [Revised the Table]
1.4 Grounding
Enclosed Display Style Console Type HIS (LPCKIT) [Revised the figure of FCS]
2.5.4 19-inch Rack Mount Devices
Providing Space for Heat Radiation [Revised the description]
3.4 Power and Ground Cabling [Revised the figure of FCS]
3.5 Connecting Signal Cable
AFF50S/AFF50D,ANR10S/ANR10D Wiring [Added IMPORTANT and revised the figure]
FIO with KS Cable Interface Adapter Cabling [Revise the figure]
3.10 Alarm and Contact I/O Cabling [Changed the number CSA 1010 to CSA 61010]
4. Installation Specifications
YPCKIT [Revised the Table]
Feb. 2009 / 13th Edition
1. System Installation Requirement
1.2 Control Room Environment
Applied Standards [Revised the Standards Noumber]
3. Cabling
3.4 Power and Ground Cabling
PFCS/PFCD Field Control Station [Revised the comment on figure]
YAX101 General-Purpose Desk [Revised the comment on figure]
YAX801 General-Purpose Desk [Revised the comment on figure]
3.8 Connecting Bus Cable
ER Bus [Added “ER Bus Converter Adapter”]
ER Bus [Added “10 Base-5 Cable”]
4. Installation Specifications
Parts Durability [Corrected]
Parts Durability [Revised the table title]
LOPSVMK [Changed the S9002KA and S9020KA to A1025EM and A1043EM]
Feb. 1, 2009-00
