3. Cabling
3-33
TI 33Q01J10-01E
Connecting Signal Cables to Terminals (for FIO)
Connecting to Pressure-clamp Terminal
1. Loosen the cable connecting terminal screw.
2. Strip the cable coating (without a sleeve) or attach a sleeve to the cable, then insert the tip of
the cable into the connecting section of the pressure clamp terminal.
3. Fasten the screw using the special tool (a screw driver conforming to the DIC 5264B
standard with a tip width of 0.6 mm and a shaft diameter of 3.5 mm) with a fastening torque
of 0.5 N•m.
Terminal screwCable terminal
ATA4S-00 S1
F030507.ai
Figure Connecting Signal Cable to Terminal (for FIO)
Do not use non-standard signal cable or sleeve; using them could cause improper connection.
Be sure to remove the cable sheath just as much as specified, fit the sleeve, and clamp the cable
firmly to the terminal.
May 18, 2007-00
To Next Page
