3. Cabling
3-61
TI 33J01J10-01EN
3.6.2 List of Signal Cables for Connection with FIO
Table Signal Cables for Connection with FIO (1/3)
Module Name
I/O channels
per Module
Connection Signal
Pressure
Clamp
Terminal
Yokogawa-
specic
Cable (*1)
MIL
Cable
Analog I/O Modules
AAI141 Analog Input Module (4 to 20 mA, Non-Isolated) 16 x x x
AAV141 Analog Input Module (1 to 5 V, Non-Isolated) 16 x x x
AAB141
Analog Input Module
16 – x –
AAI841
(4 to 20 mA Input, 4 to 20 mA Output, Non-Isolated)
x x x
AAB841
(1 to 5 V Input, 4 to 20 mA Output, Non-Isolated)
x x x
AAB842
Non-Isolated)
– x –
AAI143 Analog Input Module (4 to 20 mA, Isolated) 16 x x x
AAI543 Analog Output Module (4 to 20 mA, Isolated) 16 x x x
AAV144 Analog Input Module (-10 to +10 V, Non-Isolated) 16 x x x
AAV544
Analog Output Module
(-10 to +10 V, Non-Isolated)
16 x x x
AAI135
Analog Input Module
(4 to 20 mA, Isolated Channels)
8 x x x
AAI835 x x x
AAT145
16 – –
AAR145
16 – –
AAP135
Pulse Input Module
(Pulse Count, 0 to 10 kHz, Isolated Channels)
8 x x x
AAP149
Pulse Input Module for compatible PM1
(Pulse Count, 0 to 6 kHz, Non-Isolated)
16 – x –
AAP849
(Pulse Count input, 4 to 20 mA output, Non-Isolated)
– x –
x : Can be connected.
– : Cannot be connected.
Oct. 5, 2018-00
To Next Page
