When Receiving Voltage Pulse Signals
SW1
RL
SW2
FIL
12 V DC/24 V DC
IN
A
INB
IN
C
Transmitter
(SW1: OFF, SW2: OFF)
Setting Items the system generation builder
SW1 (RL) : OFF (No terminating resistor)
SW2 (FIL) : OFF
+
-
F030607.ai
AAP135
Figure Voltage Pulse Input
When Receiving Current Pulse By Using the Internal Power to Drive the
Transmitter (2-wire power supply type)
Transmitter
SW1
RL
SW2
FIL
12 V DC/24 V DC
IN
A
INB
IN
C
(SW1: ON, RL selection, RL=200 ohm, 500 ohm, 1 k ohm, SW2: OFF)
Setting Items the system generation builder
SW1 (RL) : Select the value of
RL resistance
SW2 (FIL) : OFF
F030608.ai
AAP135
Figure 2-Wire Power Supply Type
This method supplies power to the transmitter, and receives the transmitter output signals as the
current pulse signals. By using the input load resistance (select from None, 200 ohm, 500 ohm, 1
k ohm), the current signal is converted to the voltage level pulse and receives it.
When Receiving Voltage Pulse By Using the Internal Power to Drive the
Transmitter (3-wire power supply type)
SW1
RL
SW2
FIL
12 V DC/24 V DC
INA
INB
IN
C
Transmitter
(SW1: OFF, SW2: OFF)
Setting Items the system generation builder
SW1 (RL) : OFF (No terminating resistor)
SW2 (FIL) : OFF
F030609.ai
AAP135
Figure 3-Wire Power Supply Type
