3. Cabling
3-79
TI 33Q01J10-01E
Mounting Clamp Filter (Ferrite Core) (for European Market)
When the system is used in Europe, attach a clamp filter (ferrite core) complying with the EMC
standard in order to use RS-232C.
Mounting Clamp Filter (Ferrite Core)
After completing the RS-232C cabling, mount the supplied clamp filter on the covering of the RS-
232C cable to provide enhanced immunity to noise.
Clamp Filter Parts
Core (Part number: A1179MN with cable fastener)
The inside diameter of the core is 13±1 mm.
Clamp Filter Location
When installing a core, leave about 8 cm between the surface of the ACM11 module and the
core.
F030720.ai
Within about 8 cm
Figure Mounting Clamp Filters
May 18, 2007-00
