3. Cabling
3-60
TI 33J01J10-01EN
MIL
connector
MIL
cable
Pressure clamp terminal
KS cable interface adapter
Y
okogawa-specific
cable
T
erminal block
I/O module
F030601.ai
Figure
FIO T
erminals
Oct. 5, 2018-00
157
159
