n Grounding when joining CENTUM VP side by side with other system
Do not connect CENTUM VP’s cabinet with other cabinets electrically using bolts or other



󰀨
The CENTUM VP system in this page can also be read as cabinet of CENTUM CS 3000,
CENTUM CS, or ProSafe-RS.
CAUTION
Do not install the following systems side-by-side with CENTUM VP:
 
 
• System containing high frequency sources.
G
Equipmment
F010405.ai
Grounding bus inlte
Protective grounding system
Insulating sheet
Insulating sheet
CENTUM VP
CENTUM VP
G: Grounding Bar
G
Other system
Cabinet
/Console Type
HIS
Cabinet
/Console Type
Insulating sheet material:
Thickness:
PVC or
PL-PEV, PL-PEM Bakelite
5-10 mm
Figure Grounding Using Insulating Sheets
TIP

sheet.

sheets.
