3. Cabling
3-23
TI 33J01J10-01EN
TM1
TM1
Functional grounding
terminal
(Terminal screw: M3)
READY Contact output
(Terminal screw: M4)
HK Interface Unit
F030408.ai
Internal HK Bus
HKU
Figure Cable connection of AFV30S/AFV30D (When Connecting to HKU)
Oct.5, 2018-00
