Actual Power-On In-Rush Current of Each Component
Actual in-rush current data measured for each component is listed below:
Table System Equipment Power-On In-Rush Current
Model
In-Rush current (A) In-Rush current (A) In-Rush current (A)
100 V AC 220 V AC 24 V DC
Primary Secondary Primary Secondary Primary Secondary
AFS10S FCU (19-inch rack mountable type) 32 38 103 45 17 21
AFS10D
Duplexed FCU
(19-inch rack mountable type)
56 58 208 67 32 39
AFG10S FCU (19-inch rack mountable type) 32 38 103 45 17 21
AFG10D
Duplexed FCU
(19-inch rack mountable type)
56 58 208 67 32 39
AFS20S
FCU (with cabinet)
(with maximum no. of nodes installed)
133 118 418 267 67 59
AFS20D
Duplexed FCU (with cabinet)
(with maximum no. of nodes installed)
133 118 418 267 67 59
AFG20S
FCU (with Cabinet)
(with maximum no. of nodes installed)
133 118 418 267 67 59
AFG20D
Duplexed FCU (with Cabinet)
(with maximum no. of nodes installed)
133 118 418 267 67 59
AFS30S
FCU (for FIO, 19-inch rack mountable type)
32 38 103 45 17 21
AFS30D
Duplexed FCU
(for FIO, 19-inch rack mountable type)
56 58 208 67 32 39
AFG30S
FCU (for FIO, 19-inch rack mountable type)
32 38 103 45 17 21
AFG30D
Duplexed FCU
(for FIO, 19-inch rack mountable type)
56 58 208 67 32 39
AFS40S
Field Control Unit
(for FIO, with cabinet) (with maximum no.
of 10 node units installed)
190 80 180 80 67 59
AFS40D
Duplexed Field Control Unit
(for FIO, with cabinet) (with maximum no.
of 10 node units installed)
220 140 260 120 67 59
AFG40S
FCU (with Cabinet) (with maximum no. of
10 node units installed)
190 80 180 80 67 59
AFG40D
Duplexed FCU (with Cabinet) (with
maximum no. of 10 node units installed)
220 140 260 120 67 59
AFF50S
FCU (for FIO, rack mountable type)
(with maximum no. of node units installed)
165 25 260 22 63 48
AFF50D
Duplexed FCU
(for FIO, rack mountable type)
(with maximum no. of node units installed)
165 25 260 22 63 48
PFCS/
PFCD
Field Control Station (incl. 5 I/O units) 24 17 36 19 25 24
AND20/
AND50
Node interface unit (duplexed)
(with 5 I/O units loaded)
31 66 173 88 18 12
ACB21
I/O expansion cabinet
(with maximum no. of nodes installed)
117 117 440 256 64 63
YNT511D,
YNT522D
Optical bus repeater (dual-redundant) 48 5 112 12 40 4
YNT512D Bus repeater (dual-redundant) 48 5 112 12 40 4
ACG10S Communication gateway unit 25 4 50 8 – –
ABC11D Bus converter (dual-redundant) 56 58 208 67 33 37
ACB41
I/O expansion cabinet
(with maximum no. of node units installed)
117 117 440 256 64 63
ANR10D Node unit for dual-redundant ER bus 62 5 124 5 30 23
