3. Cabling

3-24

TI 33Q01J10-01E

19-inch Rack-mount Devices and Wiring

An example of wiring when AFF50 or ANB10 is mounted to a general-purpose cabinet in the

following:

F030423.ai

General-purpose Cabinet

3 units spacing

between devices (*1)

AFF50

Node Unit

AEP7D

Ground terminal

Grounding bar

Cabinet ground

Ground bus inlet

100 ohrms

or less

Insulating plate

Power

Isolated

Isolation bush

*1: Keep a space of 3U or more for heat radiation.

Figure 19-inch Rack-mount Devices and Wiring

Oct. 22, 2007-00
