3. Cabling
3-97
TI 33Q01J10-01E
ESB Bus
The following is an example of connecting an ESB bus.
Either ESB bus branching connector or the branching connector that has a built-in ESB bus
terminator must be mounted to SB401 installed in ESB bus node unit. If a node unit is connected
next, select ESB bus branching connector. If the node unit is the last one, select the branching
connector that has a built-in ESB bus terminator.
F030811.ai
Bus1
ESB bus (duplexed)
(connected to Bus1 if single)
REVISION
U H1 H2
MODEL
AIP532
STYLE1 SI
YOKOGAWA
ESB Bus
CN1
RCV
SND-L
SND-R
Bus2
SB401+
S9879UK
SB401+
S9879UK
Bus2
to next node unit
Bus1
REVISION
U H1 H2
MODEL
AIP532
STYLE1 SI
YOKOGAWA
ESB Bus
CN1
RCV
SND-L
SND-R
AFS30D
REVISION
U H1 H2
MODEL
AIP532
STYLE1 SI
YOKOGAWA
ESB Bus
CN1
RCV
SND-L
SND-R
REVISION
U H1 H2
MODEL
AIP532
STYLE1 SI
YOKOGAWA
ESB Bus
CN1
RCV
SND-L
SND-R
ANB10D
Connector Unit
for ESB bus
(S9879UK)
Connector Unit with
Terminator for ESB bus
(S9880UK)
ESB bus cable (YCB301)
Screw tightening torque
0.291±0.049 N•m
Figure ESB bus Connection (AFS30D)
Sep. 30, 2008-00
To Next Page
