3. Cabling
3-130
TI 33J01J10-01EN
3.11 Alarm and Contact Output Cabling
IMPORTANT
n Status Contact Output Connection
below.
Table Status Contact Output
Device Status Contact Output Contact Rating
Power and processor failure 30 V DC, 0.3 A
Power and processor failure
Power and processor failure 30 V DC, 0.3 A
Power and processor failure 30 V DC, 0.3 A
Power 30 V DC, 0.3 A
ACB51
)
Power and processor failure
)
Power and processor failure
n Use of Lamps
current. It is considered to be 10 to 15 times the rated current. If the rush current exceed
is recommended to use a dim lamp resistor using 40 to 50 % of the lamp current rating, or
resistor permits detection of lamp failure.
Be sure to test the lamp before installation.
Rush current
preventing resistor
Contact
Lamp
Contact
Lamp
Check brightness when lighted.
Check brightness when lighted.
Figure Examples of Using Lamps
Oct. 5, 2018-00
To Next Page
