2. Transportation, Storage and Installation
2-19
TI 33J01J10-01EN
lIsolation from Rack
pair of insulating bushings together to each of the screw holes on the plate or the bracket on the
CAUTION
to the insulating bushings and cause damaged or broken insulating bushings.
lInstallation Procedure
side where a screw enters.
M5 screws (8 pieces)
M5 screws
Attach insulating to both
sides of the plate.
How to install insulating bushings
Rack
Rack
Insulating
bushing
(with a tapering)
Insulating
bushing
Plate
(front)
Insulating bushings (8 pieces)
Plate
Base unit
Using functional grounding
terminal to connect the
base unit to ground.
Make the grounding cable
to pass through the tray
and pull it down along the
right side of the racks.
Figure Example of Mounting FCU on a Rack
Apr. 21, 2017-00
To Next Page
