YOKOGAWA DPharp EJX***A Series User Manual

<3. Parameter Setting>
3-29
IM 01C25T01-06EN
Table 3.1 Burst parameters
Command parameter Burst Command
Burst Msg Trigger
Mode
Burst Trigger
Source
Burst Trigger Units
PV
(Pressure • Di󰀨erential
Pressure)
Cmd1:PV Continuous --- ---
Window PV Depend on the
assigned variable to
PV
Rising
Falling
On-change
% range/current
(Percent of range, Loop
current)
Cmd2:% range/current Continuous --- ---
Window % range %
Rising
Falling
On-change
Process vars/current
(Loop current, Pressure
• Di󰀨erential Pressure
• Static Pressure •
Temperature)
Cmd3:Dyn vars/current Continuous --- ---
Window PV Depend on the
assigned variable to
PV
Rising
Falling
On-change
Process vars/% range/
current
Mapping by user
Cmd9:Device vars w/status Continuous --- ---
Window Top of Burst
Device Variables
Depends on mapping
Rising
Falling
On-change
Self diagnosis information Cmd48:Read
Additional Device Status
Continuous --- ---
On-change All status ---
*1: Output the data with time and status.
