5. Parameter Summary
Contents and Default values in the table are for 4 to 20 mA output type. For 1 to 5 V output, replace the current
mA value with corresponding voltage V value. Refer to ‘1.3 Abbreviation and Marking.’
Function Label Item Contents Default value Handling *
1
Analog output AO alm typ Analog output alarm type High or Low R
AO lower limit Lower limit of analog output 3.6000 to 21.6000 mA 3.6000 mA W
AO upper limit Upper limit of analog output 3.6000 to 21.6000 mA 21.6000 mA W
Auto recover Auto-recover from hardware error O󰀨 or On On W
Analog output
trim
Clear D/A trim Reset analog output trim M
D/A trim Analog output trim with ammeter M
Scaled D/A trim Analog output trim with voltmeter M
Channel ags Analog channel ags 0x00 R
Bi-directional
mode
Bi-dir mode Bi-directional mode O󰀨 or On O󰀨 W
Burst mode
4-20mA
Burst mode Burst mode *
2
O󰀨 or On
HART 5
O󰀨 or Wired HART Enabled
HART 7
O󰀨 W
Burst option
HART 5
Burst option Xmtr Variables, PV, % range/
current, Process vars/crnt
W
Burst Command
HART 7
Burst Command *
2
Cmd 1: PV
Cmd 2: % range/current
Cmd 3: Dyn vars/current
Cmd 9: Device vars w/status
Cmd 48: Read Additional
Device Status.
Cmd 1: PV W
Burst Variable
Code (DD)
Device Variable
Code (DTM)
HART 7
Device Variable for the Burst
Message *
2
Max 8 slots. W
Burst Msg Trigger
Mode
HART 7
Burst Trigger Mode Selection Code
*
2
(Continuous, Window, Rising,
Falling, On-change)
Continuous R
Set Burst Trigger
HART 7
Congure burst trigger Congure Burst Msg Trigger
Mode and Burst Trigger Level
M
Set Burst Period
HART 7
Congure burst period Congure Update Period and
Max Update Period
M
Burst Trigger Level
HART 7
Burst Trigger Level *
2
0.0 R
Update Period
HART 7
Update Period for Burst mode *
2
Update period for burst
message
Burst Message
1: 0.5s
2: 60s
3: 60s
R
Max Update Period
HART 7
Max Update Period for Burst mode
*
2
Maximum update period for
burst message
60 min R
Damping Pres Damp Damping time constant for DP 0.00 to 100.00 s W
Quick resp Quick response On or O󰀨 O󰀨 W
Date Date Date **/**/** W
Descriptor Descriptor Descriptor 16 alphanumerics W
*1: Handling:
R
=Read only,
W
=Read & Write,
M
=Method,
A
=Applicable for option code AL,
G
=Applicable for option code DG6,
D
=Applicable for di󰀨erential pressure transmitters. Do not change these parameters for pressure transmitters.
*2: Max three Burst Messages (Burst Message 1, Burst Message 2, Burst Message 3)
*3: The default value shows MWP (Maximum working pressure) of the capsule.
Since the working pressure limit varies according to the Model, refer to the General Specications section in each user’s manual.
*4: For output signal code J, refer to the section 3.3.18.
*5: These parameters may contain adjustment values based on the customer range calibration at the factory upon shipment.
When executing “Clear P sensor trim”, P LTD and P UTD will become “0”, and P LTP and P UTP will become the value of LRV and
URV respectively.
