4.2.3 Heat Trace Monitoring
The transmitter with Heat trace monitoring function
calculates the ange temperature by using the two
temperature sensors built in the transmitter.
An analog alert is generated if the temperature
reached to the preset level.
The ange temperature is based on the following
parameters and calculation formula.
[Parameters]
Parameter name Explanation
Snsr temp (CT) Measured capsule temperature
value
Amp temp (AT) Measured amplier temperature
value
Flg temp (FT) Flange temperature value
(Calculated value)
Flg Temp Coef (Cf) Coe󰀩cient to calculate ange
temperature
Flg Temp Hi Alert Val Threshold to generate FT high
alarm
Flg Temp Lo Alert Val Threshold to generate FT low
alarm
[Calculation formula]
Flg temp (FT) = CT + Cf X (CT-AT)
If the ange temperature exceeds the value preset
to FlgTempHiAlertVal or FlgTempLoAlertVal,
an alert is generated.
NOTE
The ange temperature is calculated by the
calculation formula assumed that the capsule
part of the transmitter is heated up or kept warm
by an electrical heater or steam. In the case of an
atmosphere temperature or less, the di󰀨erence
of temperature of approximately 3 to 4 °C,
may occur because the amplier temperature
becomes higher than the capsule temperature.
4.2.3.1 FlgTempCoefSetting
The value calculated according to the following
procedure is set to FlgTempCoef.
• To enhance the calculation accuracy of the
ange temperature, measure the actual ange
temperature by using the temperature sensor
etc.
• Calculate the ratio of the capsule temperature
to the capsule temperature minus the amplier
temperature from the two temperature values
measured by the transmitter.
• Derive the FlgTempCoef from the measured
ange temperature and the ratio of the capsule
temperature to the amplier temperature in
accordance with the following calculation
formula.
FlgTempCoef(Cf)=
(Actual measured value of Flange temperature) - CT
CT - AT
For DTM (HART 5), Flg Temp Coef parameter can
be set by using Tuning function.
By setting the measured value of ange
temperature, Flg Temp Coef is calculated by using
capsule temperature and amplier temperature.
• Procedure to call up the Tuning display.
Diag and Service → Advanced Diag Conguration →
Heat Trace → Tuning
