App-22 IM 04L20A01-01E
<#3 FTP transfer file> (/C7 Option)
Parameter Selectable Range or Selections Initial Value
FTP transfer file > Disp&Event data On/Off Off
FTP transfer file > Report On/Off Off
FTP transfer file > Snapshot On/Off Off
<#4 FTP connection> (/C7 Option)
Parameter Selectable Range or Selections Initial Value
FTP connection Primary or Secondary Primary
FTP connection > FTP server name Up to 64 alphanumeric characters –
FTP connection > Port number 1 to 65535 21
FTP connection > Login name Up to 32 alphanumeric characters –
FTP connection > Password Up to 32 alphanumeric characters –
FTP connection > Account Up to 32 alphanumeric characters –
FTP connection > PASV mode On/Off Off
FTP connection > Initial path Up to 64 alphanumeric characters –
<#5 Control (Login, Timeout)> (/C7 Option)
Parameter Selectable Range or Selections Initial Value
Ethernet login > Use/Not Use/Not Not
Ethernet login > Level admin, user1, user2, user3, user4, user5, admin
or user6
Ethernet login > Level > On/Off On/Off On
Ethernet login > Level > User name Up to 16 alphanumeric characters admin
Ethernet login > Level > Password Up to 6 alphanumeric characters 0
Application time out On/Off Off
Application time out > Time 1 to 120 1 min
Keep alive On/Off On
<#6 Serial, Memory out> ([#1] on models without /C7) (/C2 or /C3 Option)
Parameter Selectable Range or Selections Initial Value
Serial > Baud rate 1200, 2400, 4800, 9600, 19200, or 38400 bps 9600 bps
Serial > Data length 7 or 8 8 bit
Serial > Parity Odd, Even, and None Even
Serial > RS-232 > Handshaking Off:Off, XON:XON, XON:RS, or CS:RS Off:Off
Serial > RS-422/485 > Address 1 to 32 1
Serial > Protocol Normal, Modbus, Modbus-M Normal
Memory output Ethernet or Serial Ethernet
<#7 Modbus master (BASIC)> ([#2] on models without /C7) (/C2 or /C3 Option)
Parameter Selectable Range or Selections Initial Value
Basic settings > Read cycle 125 ms, 250 ms, 500 ms, 1 s, 2 s, 5 s, 10 s 1 s
Basic settings > Timeout 125 ms, 250 ms, 500 ms, 1 s, 2 s, 5 s, 10 s, or 1 min 1 s
Basic settings > Retrials Off, 1, 2, 3, 4, 5, 10, or 20 1
<#8 Modbus master (COMMAND)> ([#3] on models without /C7) (/C2 or /C3 Option)
Parameter Selectable Range or Selections Initial Value
Command settings > 1 to 8 On/Off Off
Command settings > 1 to 8 > First, Last C01 to C12 C01, C01
Command settings > 1 to 8 > Addr. 1 to 247 1
Command settings > 1 to 8 > Regi. Input registers: 30001 to 39999, 300001 to 365535 30001
Hold registers: 40001 to 49999, 400001 to 465535
Command settings > 1 to 8 > Type INT16, UINT16, INT32_B, INT32_L, UINT32_B, INT16
UINT32_L, FLOAT_B, or FLOAT_L
Appendix 6 List of Parameters
To Next Page
