Page #218 background image
12-6 IM 04L20A01-01E
12.4 Data Storage Specifications
Storage Medium
Item Specifications
Internal memory Used for temporary data storage
External storage medium Selectable from:
• Non
• 3.5-inch floppy disk (2HD, 1.44 MB)
• Compact flash memory card (32 to 512 MB)
Data Type
Item Specifications
Data type (file extensions) Display data (.dds), event data (.dev), manual sampled data (.dmn)
Setup data (.pnl)
Screen image data (.png)
On models with computation function: TLOG data (.dtg), report data (.dhr, .ddr, .dwr, .dmr)
Display Data/Event Data
Item Specifications
Internal memory capacity 1.2 MB
When writing both display data and event data: 0.9 MB for display data, 0.3 MB for event data
Display data
Objective channels All channels
Sampling interval Linked with the waveform display update rate
FX103: 0.5,1, 2, 4, 10, 20, 30, 40, 60, 120, 240, 480, 1200 s
FX106: 2, 4, 10, 20, 30, 40, 60, 120, 240, 480, 1200 s
FX112: 2, 4, 10, 20, 30, 40, 60, 120, 240, 480, 1200 s
Data acquired Max./min. values over the sampling intervals
Data size Measured data: 4 bytes per data
Computed data: 8 bytes per data
Format Binary
Acquisition method Acquires data continuously.
The newest data overwrites the oldest data in the memory when the internal memory is full.
Event data
Objective channels All channels
Sampling interval FX103: 250, 500 ms, and 1, 2, 5, 10, 30, 60, 120 s, 300 s, 600 s
FX106: 1, 2, 5, 10, 30, 60, 120, 300, and 600 s
FX112: 1, 2, 5, 10, 30, 60, 120, 300, and 600 s
Data acquired Data at the sampling intervals
Data size Measured data: 2 bytes per data
Computed data: 4 bytes per data
Format Binary
Acquisition method Free: Acquires data continuously
The newest data overwrites the oldest data in the memory when the internal memory is
full.
Trigger: Starts data acquisition when a specified event occurs. Acquires data for a specified time.
No more acquisition starts when all blocks are full.
Rotate: Starts data acquisition when a specified event occurs. Acquires data for a specified time.
Overwrites the oldest block in the memory when all blocks are full.
Combination of data to be acquired
Selectable from:
Display data only,
Event data only, or
Display data and event data (only for trigger or rotate mode).
