Chapter 10 Troubleshooting
10.1 A List of Messages
Occasionally, error codes and messages appear on the screen while using the FX100.
The entire list of messages is given below.
Errors Related to Parameter Settings
•Setting Errors
Code Message Explanation/Countermeasures/Ref. section
1 System error. Contact your nearest YOKOGAWA dealer.
2 Incorrect date or time setting. Check the settings. See section 3.3.
3A disabled channel is selected. Check communication command parameters.
Confirm the number of channels of the FX100.
4 Incorrect function parameter. Check communication command parameters.
5 The input numerical value exceeds the set range. Enter a proper value.
6 Incorrect input character string. Enter a proper character string.
7 Too many characters. Enter specified number of characters.
8 Incorrect input mode. Check communication command parameters.
See section 4.1.
9 Incorrect input range code. Check communication command parameters.
See section 4.1.
21 Cannot set an alarm for a skipped channel. Check communication command parameters.
Confirm the mode setting. See section 4.1.
22 The upper and lower span limits are equal. Cannot be the same value. See section 4.1.
23 The upper and lower scale limits are equal. Cannot be the same value. See section 4.1.
30 The partial boundary value exceeds the range of the span. Select a value within the measurement span.
See section 6.12.
31 Partial expansion display is set ON for a SKIPPED channel. Check communication command parameters.
Confirm the mode setting. See section 4.1.
35 The upper and lower limits of the display band are equal. (upper limit) > (lower limit). See section 6.7.
36 The lower limit of the display band is greater than the upper limit. (upper limit) > (lower limit). See section 6.7.
37 The display band is narrower than 4% of the entire display. (upper limit)−(lower limit) > 5%. See section 6.7.
40 Incorrect group set character string. Example: 01.03.05-08. See section 6.1.
41 There is no specified input channel. Check communication command parameters.
FX103: 1 to 3, FX106: 1 to 6, FX112: 1 to 12
42 Exceeded the number of channels which can be set. Check communication command parameters.
FX103: 1 to 3, FX106: 1 to 6, FX112: 1 to 12
43 A channel number cannot repeat in a group. A channel cannot be assigned twice or more to a
group. See section 6.1.
45 There is no character string saved in the clipboard. Copy a character string to the clipboard.
46 The character string saved in the clipboard is too long. Paste a character string with the proper number
of characters.
61 There is no channel specified by the MATH expression. FX103: 1 to 3, FX106: 1 to 6, FX112: 1 to 12,
Computation channels: 31 to 42.
62 MATH expression grammar is incorrect. Check the expression. See appendix 2.
63 MATH expression sequence is incorrect. Check the expression. See appendix 2.
64 MATH upper and lower span values are equal. Cannot be the same value. See section 8.1.
70 MATH constant description is incorrect. Maximum number of significant digit is 5.
See section 8.1.
71 The range of the MATH constant is exceeded. −9.9999E+29 to −1.0000E−30, 0, 1.0000E−30 to
9.9999E+29. See section 8.1.
81 All space or ‘quit’ string cannot be specified. Use other string as a user name. See section 9.3.
85 The login password is incorrect. Enter a correct password. See section 9.3.
86 The key-lock release password is incorrect. Enter a correct password. See section 9.2.
