12-17
IM 04L20A01-01E
Specifications
12
12.7 Dimensional Drawings
144 (5.67)
151.5 (5.96)
23.4
(0.92)
175 (6.89)
7.5 (0.30)
58.4
(2.30)
136.5 (5.37)
144 (5.67)
151.5 (5.96)
9.4 (0.37)
Thickness of the attachment panel
2 to 26
(Dimensions before the mounting
bracket is attached)
(Dimensions after the mounting
bracket is attached)
Unit: mm (approx. inches)
NO.
STYLE
MODEL
TAG NO.
TAG NO.
TAG NO.
TAG NO.
TAG NO.
TAG NO.
SUFFIX
SUPPLY
FREQUENCY
10Base-T
RS-422A/485
FG SG
SDB SDA RDB RDA
Option terminal block
Measurement input
terminal blocks
Power terminals
The dimensional tolerance is ±3% unless otherwise specified. (However, the tolerance for
dimensions less than 10 mm is ±0.3 mm).
Note
When mounting to a panel, use two brackets, one each of the top and bottom of the FX100,
or on the left and right sides.
To Next Page
