12-16 IM 04L20A01-01E
Item Specifications
Input source resistance Volt, TC: 2 kΩ or less
RTD: 10 Ω or less per wire (The resistance of all three wires must be equal).
Input bias current 10 nA or less (without burnout detection)
Common mode rejection ratio
120 dB (50/60 Hz ±0.1%, 500 Ω imbalance, between the minus terminal and ground)
Normal mode rejection ratio
40 dB (50/60 Hz ±0.1%)
Noise reduction method Reduced by integral type A/D converter and low pass filter
Maximum common mode voltage
±60 V DC (under measurement category II)
However, maximum common mode voltage that meets the rejection ratio is 250 Vrms AC (50/60 Hz)
Maximum common mode voltage between channels
250 Vrms AC (50/60 Hz)
Parallel capacitance for RTD input
0.01µF or less
Measurement input terminal
Cramped input terminal
Terminal blocks are removable.
Wire gauge: 0.2–2.5 mm
2
(AWG24–AWG17)
Effects of Operating Conditions
Item Specifications
Ambient temperature With temperature variation of 10°C:
±(0.1% of rdg + 1 digit) or less for Volt ranges
±(0.1% of rdg + 1 digit) or less for TC ranges
Excluding the error of reference junction compensation
±(0.1% of rdg + 2 digit) or less for RTD ranges
Power supply Except for /P1 model
With variation within 90 to 132 V and 180 to 250 VAC (50/60 Hz): ±1 digit or less
With variation of ±2 Hz from rated power frequency (at 90 to 132 VAC, 180 to 250 VAC): ±(0.1% of
rdg + 1 digit) or less
/P1 model
With variation within 21.6 to 26.4 VDC/AC (50/60 Hz): ±1 digit or less
With variation of ±2 Hz from rated power frequency (at 24 VAC): ±(0.1% of rdg + 1 digit) or less
Magnetic field AC (50/60 Hz) and DC 400 A/m fields: ±(0.1% of rdg + 10 digits) or less
Input source resistance
Volt range With variation of +1 kΩ:
Ranges of 200 mV or less: within ±10 mV
Ranges of 2 V or greater: ±0.1% of rdg or less
TC range With variation of +1 kΩ:
Within ±10 µV (±100 µV when the burnout detection function is switched on)
RTD range (Pt100) With variation of 10 Ω per wire (resistance of all three wires must be equal):
±(0.1% of rdg + 1 digit) or less
With maximum difference of 40 mΩ between wires: approximately 0.1°C
RTD range (Pt1000)
*
With variation of 10 Ω per wire (resistance of all three wires must be equal):
±(0.1% of rdg + 1 digit) or less
With maximum difference of 400 mΩ between wires: approximately 0.1°C
* /N3 option
Other Specifications
Item Specifications
Clock With calendar function (year of grace)
The time can be adjusted by a remote input (remote control option).
Daylight saving Summer and wintertime can be set.
Accuracy of clock ±100 ppm, excluding a delay (of 1 second, maximum) caused each time the power is turned on.
Memory backup A built-in lithium battery backs up the setup parameters (battery life: approximately ten years at
room temperature).
Key lock function ON/OFF and password can be set.
Key login function Logs in using user name, user ID and password.
USER key Executes various actions assigned.
12.6 General Specifications
