YOKOGAWA SMARTDAC+ GX10 User Manual

17
All Rights Reserved. Copyright © 2012, Yokogawa Electric Corporation
GS 04L52B01-01EN
Nov. 10, 2015-00
StandardAccessories
Product Qty
SDmemorycard(1GB) 1
Stylus pen (touch pen) 1
Tagsheet(forGP10orGP20) 1
Sheet(paper)(forGP10orGP20) 1
Power cord 1
ApplicationSoftware (SoldSeparately)
Model Description OS
DXA170 DAQStudiosoftware WindowsVista/7/8/8.1
GA10 DataLoggingSoftware Windows
Vista/7/8.1/10
WindowsServer
2008/2012
 OptionalAccessories(SoldSeparately)
Product Model/partno.
ModelSDmemorycard(1GB) 773001
Stylus pen (touch pen) B8740BZ
ShuntresisterforM3terminal(10Ω±0.1%)
X010-010-3
ShuntresisterforM3terminal(100Ω±0.1%)
X010-100-3
ShuntresisterforM3terminal(250Ω±0.1%)
X010-250-3
ShuntresisterforClampterminal(10Ω±0.1%)
438922
ShuntresisterforClampterminal(100Ω±0.1%)
438921
ShuntresisterforClampterminal(250Ω±0.1%)
438920
Dummycover B8740CZ
ValidationDocuments(For/ASoption)*1 773230
*1 ProvisionofValidationDocuments
 Alicensesheetcontainingthelicensekey
requiredforinstallationisprovided.
 Downloadthevalidationdocumentfromthe
followingURL.
 http://www.smartdacplus.com/software/en/
Calibrationcerticate(soldseparately)
WhenorderingtheGP10/GP20withoptions(analoginput),thecalibrationcerticateforthemodulesisincludedin
andshippedwiththecalibrationcerticateofthemainunit.Whenorderingananaloginputmoduleseparately,each
modulegetsitsowncalibrationcerticate(onecerticatepermodule).
Testcerticate(QIC,soldseparately)
WhenorderingtheGP10/GP20withoptions(analog/digialI/O),theQICforeachmoduleisincludedinandshipped
withtheQICofthemainunit.WhenorderinganaloginputmodulesanddigitalI/Omodulesseparately,eachmodule
getsitsownQIC(oneQICpermodule).
User'sManual
Productuser'smanualscanbedownloadedorviewedatthefollowingURL.Toviewtheuser'smanual,youneedto
useAdobeReader7orlaterbyAdobeSystems.
URL:www.smartdacplus.com/manual/en/
ProductPurchaseSpecications
TheGP10/GP20iscomposedofthemainunit,I/Omodules,ExpandableI/O,andExpansionmodule.
TherearetwowaystopurchaseI/Omodules.
OnewayistopurchasethemindividuallybyspecifyingmodelsGX90XA,GX90XD,GX90YD,GX90WDand
GX90XP.
Theotherwayistopurchasethemasanoption(/UCxxor/USxx).Purchasingthemasanoptionisconvenient,but
thisplaceslimitationsonthenumberofanaloginputsthatyoucanobtain.
Ifyouwanttousemorethan50channels,pleasepurchasetheI/Omodulesindividually.
ToconnectexpandableI/O(GX60)toGP10orGP20,youmustpurchaseoneunitofexpansionmodule(GX90EX)
forGP10/GP20inadditiontotheexpandableI/O.
Trademarks
 TheTCP/IPsoftwareusedinthisproductandthedocumentforthatTCP/IPsoftwarearebasedinpartonBSD
networkingsoftware,Release1licensedfromTheRegentsoftheUniversityofCalifornia.
•SMARTDAC+andSMARTDACPLUSaretrademarksofYokogawaElectricCorporation.
•Microsoft,MSandWindowsareregisteredtrademarksofMicrosoftCorporationUSA.
•PentiumareregisteredtrademarksofIntelCorporation.
•ModbusisaregisteredtrademarkofAEGSchneider.
•KerberosisatrademarkofMIT.
•JavaandJava-relatedtrademarksaretrademarksorregisteredtrademarksofSunMicrosystems,Inc.intheUnited
States and/or other countries.
•Othercompanyand/orproductnamesareregisteredtrademarkoftheirmanufactures.
