General
Specications
GX60
I/O Base Unit (Expandable I/O)
GX90EX
Expansion Module
Yokogawa Electric Corporation
2-9-32, Nakacho, Musashino-shi, Tokyo, 180-8750 Japan
GS 04L53B00-01EN
GS 04L53B00-01EN
©Copyright April 2014
4th Edition Nov. 10, 2015
 OVERVIEW
GX60 I/O Base Unit (Expandable I/O)
The GX60 provides a function to expand an I/O
module for recording and controlling, when it is
connected to the expansion module that is connected
to the GX10/GX20/GP10/GP20 using a LAN cable via
a private communication network.
● OneGX60canconnectuptosixI/Omodules.
● Uptosixunitscanbeadditionallyconnectedto
the GX/GP.
● Thecommunicationdistancebetweenthe
GX/GP and GX60 or between GX60s can be
extendedbyupto100musingaLANcable.
GX90EX Expansion Module
The expansion module is connected to the GX10/
GX20/GP10/GP20, GX60, GM main unit, and GM sub
unit.
[IfGX90EXexpansionmoduleisconnectedtotheGX/
GP or I/O base unit]
● Theexpansionmodule,whichissupportedby
the GX/GP and GX60, enables a connection
betweenGX/GPandGX60oracommunication
between GX60s.
● Adistributedarrangementwiththedata
timesynchronizationsecuredisprovidedby
connectingExpansionmodulesconnectedtothe
GX/GPmainunitandGX60usingaLANcable.
● Dataistransferredtothehigh-orderGX/GPvia
theexpansionmodule.
[IfGX90EXexpansionmoduleisconnectedtotheGM
mainunit/subunit]
● Theexpansionmodule,whichissupported
bytheGMmainunitandsubunit,enablesa
connectionbetweenGMmainunitandsubunit
oracommunicationbetweensubunits.
● Adistributedarrangementwiththedata
timesynchronizationsecuredisprovidedby
connectingExpansionmodulesconnectedtothe
GMmainunitandsubunitusingaLANcable.
● Dataistransferredtothehigh-orderGM10via
theexpansionmodule.
GX90EX
GX60
Power inlet type
Power Screw type
