<Toc> < 1. Installation >
1-3
IM 05D01C02-41E 3rd Edition: May 31, 2006-00
■ External Dimensions and Panel Cutout Dimensions
PV
AL1 2 3 4
CAS
SET/ENT
A/M
REM
MAN
LP2
(25)
(53)
[(N-1)96+92]117 min.
145 min.
+0.8
0
+0.8
0
92
+0.8
0
92
+0.8
0
92
“N” stands for the number of controllers to be
installed.
However, the measured value applies if N  5.
100
11
UT550
General installation Side-by-side close installation
1 to 10 mm (Panel thickness)
Small bracket
Large bracket
91.8
112
Unit: mm
96
96
PV
AL1 2 3 4
REM MAN
LP2 CAS
SET/ENT
A/M
[(N-1)48+45]
+0.6
0
+0.8
0
92
“N” stands for the number of controllers to be
installed.
However, the measured value applies if N  5.
10048
11
UT520
Small bracket
Small bracket
91.8
96
112
Unit: mm
70 min.
45
+ 0.6
0
(25)
(53)
92
+ 0.8
0
145 min.
1 to 10 mm
(Panel thickness)
General installation Side-by-side close installation
