YOKOGAWA UT550 User Manual

5-18
<Toc> < 5. Parameters >
IM 05D01C02-41E 3rd Edition: May 31, 2006-00
● SELECT Display Parameters
Located in: Main menu =
(CONF)
; Submenu =
(CSEL)
Parameter
Symbol
Name of Parameter Setting Range and Description Initial Value
SELECT display-1
registration
OFF (0), 201 to 1023
Select the desired parameter from among the operating
and setup parameters, then register the number
(D register No.) accompanying that parameter.
For example, registering “302” for C.S1 allows you
to change alarm-1 setpoint in operating display.
Numbers for registering alarm SP parameter
for operating display:
Alarm-1 setpoint: 302
Alarm-2 setpoint: 303
Alarm-3 setpoint: 304
Alarm-4 setpoint: 305
Above numbers are alarm setpoint parameters for target
setpoint-1 (1.SP).
Set the registration number of the alarm setpoint parameter for
target setpoint 2 (2.SP), to a value obtained by adding 25 to the
registration number of the alarm setpoint parameter for the
parameter 1.SP.
Likewise, set the registration number of the alarm setpoint
parameter for target setpoint 3 (3.SP), to a value obtained by
adding 25 to the registration number of the alarm setpoint
parameter for the parameter 2.SP.
Likewise, the registration number for 4.SP to 8.SP can be
obtained.
OFF (0)
SELECT display-2
registration
User
Setting
Target Item
in CD-ROM
SELECT display-3
registration
SELECT display-4
registration
SELECT display-5
registration
(C.S1)
(C.S2)
(C.S3)
(C.S4)
(C.S5)
Ref.6.1(1)
Same as
above
Same as
above
Same as
above
Same as
above
● Contact Output Registration Parameters
Located in: Main menu =
(CONF)
; Submenu =
(DO)
Parameter
Symbol
Name of Parameter Setting Range and Description Initial Value User
Setting
Target Item
in CD-ROM
Relay output flag
registration for DO1
The following setpoints are registration numbers for Single-loop
Control only.
5689: Alarm-1 output
5690: Alarm-2 output
5691: Alarm-3 output
5693: Alarm-4 output
1609: FAIL output
5689
5690
5691
Relay output flag
registration for DO2
Relay output flag
registration for DO3
(DO1)
(DO2)
(DO3)
5693
Open-collector transistor
output flag registration
for DO4
(DO4)
0
0
1609
Open-collector transistor
output flag registration
for DO5
Open-collector transistor
output flag registration
for DO6
Open-collector transistor
output flag registration
for DO7
(DO5)
(DO6)
(DO7)
Ref.3.2(1)
Same as
above
Same as
above
Ref.3.2(1)
Same as
above
Same as
above
Same as
above
