<Toc> < 5. Parameters >
5-17
IM 05D01C02-41E 3rd Edition: May 31, 2006-00
● Deviation Monitor Parameters
Located in: Main menu =
(CMLP)
; Submenu =
(TRND)
Parameter
Symbol
Name of Parameter Setting Range and Description Initial Value
Deviation display band 0.0 to 100.0% of PV input range span
Permits a change in the span of deviation shown on the
front-panel deviation monitor.
1.0% of PV
input range
span
User
Setting
Target Item
in CD-ROM
(DVB)
Ref.6.1(3)
● Security-related Parameters
Located in: Main menu =
(CMLP)
; Submenu =
(LOCK)
Parameter
Symbol
Name of Parameter Setting Range and Description Initial Value
Front panel data setting
( , ) key lock
OFF (0): Unlock
ON (1): Lock
OFF (0)
Front panel A/M key
lock
OFF (0): Unlock
ON (1): Lock
OFF (0)
User
Setting
Target Item
in CD-ROM
(A/M)
(DAT)
OFF (0): Unlock
ON (1): Lock
OFF (0)
OFF (0): Unlock
ON (1): Lock
OFF (0)
(LP1)
(MOD)
Although not used in Single-loop Control, it is shown on the display.
OFF (0): Unlock
ON (1): Lock
OFF (0)
(PID)
(LP2)
Although not used in Single-loop Control, it is shown on the display.
OFF (0): Unlock
ON (1): Lock
OFF (0)
(PY1)
(USR)
Although not used in Single-loop Control, it is shown on the display.
Password setting 0: Password not set
1 to 30000
0
(PWD)
(PY2)
Operating parameter
main menu [MODE]
lock
Operating parameter
main menu [LP1] lock
Operating parameter
main menu [PID] lock
Operating parameter
main menu [PYS1] lock
Ref.7.1(2)
Ref.7.1(1)
Same as
above
Same as
above
Same as
above
Same as
above
Same as
above
