Parameter
Symbol
Name of Parameter Setting Range and Description Initial Value User
Setting
Target Item
in CD-ROM
PV unit Set the unit of PV.
% (0): Percent F (5): Fahrenheit
C (1): Degree Celsius
- (2): No unit
Same as the
unit of PV input
(P.U1)
PV decimal point
position
Under normal operation, set the same value as in the PV Input
Decimal Point Position (DP1) parameter.
To shift the decimal point for temperature input, use this parameter.
For example, set as “P.D1 = 0” to change a temperature reading
of one decimal place to that of no decimal places. This involves
reconfiguring the P.H1 and P.L1 parameters.
0 to 4
-
Maximum value
of PV range
Under normal operation, keep the values of these parameters
between the maximum and minimum values of the PV input
range.
-19999 to 30000
P.L1 < P.H1, where P.H1-P.L1  30000
Maximum value
of PV input
range or scale
Minimum value of
PV range
Minimum value
of PV input
range or scale
(P.D1)
(P.H1)
(P.L1)
Remote input
burnout action
selection
Allows the remote input value to be determined as shown below
in case of remote input burnout.
• 105% of remote input scale if set to “Upscale”
• -5.0% of remote input scale if set to “Downscale”
OFF (0): Disable
UP (1): Upscale
DOWN (2): Downscale
OFF (0)
(BO3)

Ref.1.1(8)
Same as
above
Same as
above
Same as
above
