10-7
IM 760401-01E
GP-IB Interface (Option)
10
Each output block usually consists of five lines (six in case of recall) including the block
end line “END”. However, if all output types on a line are set to “no output”, this line will
be omitted, reducing the number of output lines by one. For example, if all output items
of ch.9 to ch12 are set to “no output”, line 4 in the above example will be omitted.
Furthermore, if any channel on a line is set to “no output”, all data following this
channel on the line will be shifted forward. For example, if the ch.2 on line 1 is set to
“no output”, data of ch.1 will be followed by data of ch.3.
Output Format in case of Normal Measurement
• WT210 (760401)
V1 data
Terminator
A1 data
Terminator
W1 data
Terminator
Frequency , Display C
Terminator
END Terminator
Line 1
Line 2
Line 3
Line 4
Line 5
Line 6
Data
number
Terminator
(The data number will only be output in case of recall)
• WT230 (760502)
V1 data ,
V3 data SV data Terminator
,
A1 data ,
A3 data SA data Terminator
,
W1 data ,
W3 data SW data Terminator
,
Frequency , Display C
Terminator
END Terminator
Line 1
Line 2
Line 3
Line 4
Line 5
Line 6
Data
number
Terminator
(The data number will only be output in case of recall)
• WT230 (760503)
V1 data , V2 data V3data SV data Terminator, ,
A1 data , A2 data A3 data SA data Terminator,
,
W1 data , W2 data W3 data SW data Terminator,
,
Frequency , Display C
Terminator
END Terminator
Line 1
Line 2
Line 3
Line 4
Line 5
Line 6
Data
number
Terminator
(The data number will only be output in case of recall)
10.4 Output Measured/Computed Data, Setup Parameters, and Error Codes
