14-30 IM 760401-01E
MEASure:HARMonics:ITEM:{SYNChronize|<harmonic
measurement function>}
Function Sets the communication output item of harmonic
measurement ON/OFF, queries the current
setting.
Syntax MEASure:HARMonics:ITEM:{SYNChronize|
<harmonic measurement function>} {<
Boolean>}
MEASure:HARMonics:ITEM:{SYNChronize|
<harmonic measur2ement function>}?
SYNChronize=PLL source
<harmonic measurement
function>={VTHD|
V|VCON|ATHD|A|ACON|PF|W|WCON|VDEG|ADEG}
Example MEASURE:HARMONICS:ITEM:VTHD ON
MEASURE:HARMONICS:ITEM:VTHD?
-> :MEASURE:HARMONICS:ITEM:VTHD 1
Description The selection SYNChronize is for outputting
the frequency of the PLL source.
You can query the PLL source input by the
command HARMonics:SYNChronize?
MEASure:HARMonics:VALue?
Function Queries harmonic measurement data set by
commands other than
”MEASure:HARMonics:ITEM” (ASCII format).
Syntax MEASure:HARMonics:VALue?
Example MEASURE:HARMONICS:VALUE? ->
60.00E+00,12.01E+00,49.98E+00,
49.62E+00,0.03E+00,5.50E+00,.....
Description • The renewal of harmonic measurement data
output here occurs when bit0 (UPD) of the
condition register (refer to page 14-47) changes
from high to low. For more details, refer to 14.2.6.
• For the output format of harmonic
measurement data, refer to page 14-33.
MEASure:HEADer
Function Turns ON/OFF the additional information output
when outputting measured/computed data in
binary format.
Syntax MEASure:HEADer {<Boolean>}
Example MEASURE:HEADER OFF
MEASURE:HEADER?
-> :MEASURE:HEADER 0
Description For a description of the additional information,
see page 14-35.
MEASure:NORMal?
Function Queries all settings related to normal measured/
computed data.
Syntax MEASure:NORMal?
Example Example of WT230 three-phase four-
wire model
MEASURE:NORMAL? -> :MEASURE:NORMAL:
ITEM:V:ELEMENT1 1;ELEMENT2 1;
ELEMENT3 1;SIGMA 1;:MEASURE:NORMAL:
ITEM:A:ELEMENT1 1;ELEMENT2 1;
ELEMENT3 1;SIGMA 1;:MEASURE:NORMAL:
ITEM:W:ELEMENT1 1;ELEMENT2 1;
ELEMENT3 1;SIGMA 1;:MEASURE:NORMAL:
ITEM:VA:ELEMENT1 0;ELEMENT2 0;
ELEMENT3 0;SIGMA 0;:MEASURE:NORMAL:
ITEM:VAR:ELEMENT1 0;ELEMENT2 0;
ELEMENT3 0;SIGMA 0;:MEASURE:NORMAL:
ITEM:PF:ELEMENT1 0;ELEMENT2 0;
ELEMENT3 0;SIGMA 0;:MEASURE:NORMAL:
ITEM:DEGREE:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:VHZ:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:AHZ:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:WH:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:WHP:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:WHM:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:AH:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:AHP:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:AHM:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:VPK:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:APK:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:TIME 0;MATH 0
MEASure[:NORMal]:BINary?
Function Queries normal measurement data set by
commands other than “MEASure[:NORMal]:
ITEM” (binary format).
Syntax MEASure[:NORMal]:BINary?
Example MEASURE:NORMAL:BINARY?
-> #5(number of bytes, 5
digits)(series of data bytes)
Description For a description of the output format of normal
measurement data, see page 14-35.
MEASure[:NORMal]:ITEM?
Function Queries all settings related to the
communication output items of normal
measured/computed data.
Syntax MEASure[:NORMal]:ITEM?
Example MEASURE:NORMAL:ITEM? -> (Results are
the same as for MEASure:NORMal? )
14.3 Commands
To Next Page
