IM 01C50B01-01E
7-2
7. STANDARD SPECIFICATIONS
Ambient humidity:
5 to 100%RH at 40°C (104°F)
Effect of supply voltage fluctuation:
±0.005%/V
Insulation:
Input/output insulated at 500 V AC
Mounting:
Mounted on 2B pipes and wall
Waterproofing:
JIS0920, water-resistant type (equivalent of
NEMA TYPE4X)
Electrical connection:
Refer to “Model and Specification Codes”.
Case and cover:
Aluminum alloy casting
Painting:
Polyurethane resin baked finish
Deep sea moss green (equivalent of Munsell
0.6GY3.1/2.0)
Integral indicator (option):
LCD digital indicator (5-digit display)
Output bar graph; 0 to 100% display
Damping constant:
1 to 99 seconds (integer range that can be set)
Sensor burnout (Output Signal Code D&E) :
High (110%, 21.6 mA DC) or Low (–2.5%, 3.6
mA DC)
Weight:
1.2 kg; without built-in indicator (without mount-
ing bracket)
1.4 kg; with Integral indicator (without mounting
bracket)
EMC compliant standard: ,
EN61326, AS/NZS 2064
