7. STANDARD SPECIFICATIONS
Table 7.1 Input Type, Measurement Range and Accuracy
Sensor Type
Reference
Measurement Range
Minimum Span
Accuracy
Standard
(Recommended)
Input range
A/D Accuracy
D/A
C F
C F
C F
Accuracy
T/C
B 100 to 1820 212 to 3308
100 to 300 212 to 572 ± 3.0 ± 5.4
300 to 400 572 to 752 ± 1.0 ± 1.8
400 to 1820 752 to 3308 ± 0.75 ± 1.35
E
-200 to 1000 -328 to 1832
-200 to -50 -328 to -58 ± 0.35 ± 0.63
-50 to 1000 -58 to 1832 ± 0.16 ± 0.29
J
IEC584
-200 to 1200 -328 to 2192
-200 to -50 -328 to -58 ± 0.40 ± 0.72
25 C
-50 to 1200 -58 to 2192 ± 0.20 ± 0.36
K
-200 to 1372 -328 to 2502
(45 F)
-200 to -50 -328 to -58 ± 0.50 ± 0.90
-50 to 1372 -58 to 2502 ± 0.25 ± 0.45
N
-200 to 1300 -328 to 2372
-200 to -50 -328 to -58 ± 0.80 ± 1.44
-50 to 1300 -58 to 2372 ± 0.35 ± 0.63
R
-50 to 1768 -58 to 3214
-50 to 0 -58 to 32 ± 1.0 ± 1.8
0to 100 32 to 212 ± 0.80 ± 1.44
± 0.02%
100 to 600 212 to 1112 ± 0.60 ± 1.08
of span
600 to 1768 1112 to 3214 ± 0.40 ± 0.72
S
-50 to 1768 -58 to 3214
-50 to 0 -58 to 32 ± 1.0 ± 1.8
0to 100 32 to 212 ± 0.80 ± 1.44
100 to 600 212 to 1112 ± 0.60 ± 1.08
600 to 1768 1112 to 3214 ± 0.40 ± 0.72
T
-200 to 400 -328 to 752
-200 to -50 -328 to -58 ± 0.25 ± 0.45
-50 to 400 -58 to 752 ± 0.14 ± 0.25
W3
0to2300 32 to 4172
0to 400 32 to 752 ± 0.80 ± 1.44
400 to 1400 752 to 2552 ± 0.50 ± 0.90
1400 to 2000 2552 to 3632 ± 0.60 ± 1.08
ASTM
2000 to 2300 3632 to 4172 ± 0.90 ± 1.62
W5
E988
0to2300 32 to 4172
0to 400 32 to 752 ± 0.70 ± 1.26
400 to 1400 752 to 2552 ± 0.50 ± 0.90
1400 to 2000 2552 to 3632 ± 0.70 ± 1.26
2000 to 2300 3632 to 4172 ± 0.90 ± 1.62
L
-200 to 900 -328 to 1652
-200 to -50 -328 to -58 ± 0.30 ± 0.54
DIN43710
-50 to 900 -58 to 1652 ± 0.20 ± 0.36
U
-200 to 600 -328 to 1112
-200 to -50 -328 to -58 ± 0.50 ± 0.90
-50 to 600 -58 to 1112 ± 0.25 ± 0.45
RTD
Pt100
-200 to 850 -328 to 1562 -200 to 850 -328 to 1562 ± 0.14 ± 0.25
Pt200 IEC751 -200 to 850 -328 to 1562
10 C
-200 to 850 -328 to 1562 ± 0.30 ± 0.54
Pt500 -200 to 850 -328 to 1562
(18 F)
-200 to 850 -328 to 1562 ± 0.20 ± 0.36
JPt100
JIS C1604
SAMA
RC21-4
-200 to 500 -328 to 932 -200 to 500 -328 to 932 ± 0.16 ± 0.29
-70 to -40 -94 to -40 ± 1.35 ± 2.43
-40 to 150 -40 to 302 ± 1.0 ± 1.8
Cu -70 to 150 -94 to 302
mV
-10 to 100
[mV]
3 [mV]
± 12 [µV]
ohm
0to2000
[Ω] 20 [Ω]
± 0.35 [Ω]
T0701.EPS
Ni120 -70 to 320 -94 to 608 -70 to 320 -94 to 608 ± 0.11 ± 0.19
