<10. Other Functions>
10-39
IM 11M12G01-02EN 1sh Edition : Mar. 25, 2021-00
NOTE
Be sure not to terminate a calibration in progress because of a shortage of gas in the cylinder.
Each gas cylinder is operable for nine minutes or more provided the gas is discharged at the
zero-point calibration twice.
<Treatment after completion of calibration>
(1) Fully close the stop valve mounted on the calibration gas inlet of the detector.
(2) Remove the tube connecting the detector to the standard gas unit.
WARNING
Store the standard gas unit with the gas cylinder mounted where the ambient temperature does
not exceed 40°C. Otherwise, the gas cylinder may explode. Store the spare gas cylinders under
the same condition.
10.12 Methods of Operating Valves in the ZA8F
Flow Setting Unit
The ZA8F Flow Setting Unit is used as a calibration device for a system conforming to System
2. Calibration in such a system is to be manually operated. So, you have to operate the valve of
For operation of the converter, see Section
“7.12 Calibration”, earlier in this manual.
10.12.1 Preparation Before Calibration
To operate the ZA8F Flow Setting Unit, prepare for calibration as follows:
pressure plus approx. 50 kPa (or sample gas pressure plus approx. 150 kPa when a check
valve is used, maximum pressure rating is 300 kPa).
(2) Check that the oxygen concentration of the zero gas and span gas (instrument air 21
vol%O
2
) in the cylinder is set in the converter.
10.12.2 Operating the Span Gas Flow Setting Valve
The following description is given assuming that instrument air, the same as the reference gas, is
used as the span gas.
(1) When the display shown in Figure 10.15 appears during calibration, open the span gas
the valve slowly counterclockwise after loosening the lock nut if the valve has a lock nut. To
high, adjust the sample gas pressure to obtain pressures (listed in Table 10.7) ± 10%.
Table 10.11
Sample gas pressure (kPa) 50 100 150 200 250
Flow rate (ml/min) 500 430 380 350 320
To Next Page
