<11. Inspection and Maintenance>
11-12
IM 11M12G01-02EN 1sh Edition : Mar. 25, 2021-00
COM ON S N Z RO
F11.8E.ai
Bolt fixes bracket
Flowmeter with back plate
Connecter
Figure 11.10 Flowmeter replacement
F11.9E.ai
A
A'
B
B'
C
C'
D
D'
Two screws fix flowmeter
Connect piping pairs A-A', B-B', C-C', D-D'
Figure 11.11 Fixing Flowmeter
