YOKOGAWA ZR802G User Manual

  <2.Specications>
2-13
IM 11M12G01-02EN 1sh Edition : Mar. 25, 2021-00
F2-4E.ai
Rc1/2(Note2)
Approx. 351
180
Detector(ZR22G)
Ø52 over
Ø30
Ø60.5
Reference gas inlet Rc1/4 or 1/4NPT
Calibration gas inlet Rc1/4 or 1/4NPT
High temperature
Probe SiC pipe
110
48
25
170
Approx. 215
(Insertion length) (Note1)
Approx. 100
69
Approx. 48
C
(Note 1) L= 0.5、0.6、0.7、0.8、0.9、
1.0、1.5(m)
(Note 2) Sample gas outlet
(if the sample gas pressure is negative,
connect the auxiliary ejector.)
Ø124±3
85
Sample gas outlet
Flange provided
by customer
Unit: mm
L
t
Flange (Thickness 5)
JIS 5K 32 FF equivalent
Gasket (Thickness 1.5)
Flange <1>
Ø60.5
ØB
ØA
Pipe hole (2- G1/2, 2-1/2NPT, etc)
ØA
Ø115
Flange<1> A B C t
JIS 5K 50 FF 130 105 4 - Ø15 14
JIS 10K 65 FF 175 140 4 - Ø19 18
JIS 10K 80 FF 185 150 8 - Ø19 18
JIS 10K 100 FF 210 175 8 - Ø19 18
ANSI Class 150 4 RF 228.6 190.5 8 - Ø19 24
ANSI Class 150 3 RF 190.5 152.4 4 - Ø19 24
ANSI Class 150 2 RF 177.8 120.6 4 - Ø19 19
JPI Class 150 4 RF 229 190.5 8 - Ø19 24
JPI Class 150 3 RF 190 152.4 4 - Ø19 24
DIN PN10 DN50A 165 125 4 - Ø18 18
