York OPTIVIEW - FIGURE 2 - Refrigerant Flow-Thru Chiller

JOHNSON CONTROLS
10
FORM 160.78-O2
ISSUE DATE: 5/22/2017
SECTION 1 - DESCRIPTION OF SYSTEM AND FUNDAMENTALS OF OPERATION
FIGURE 2 - REFRIGERANT FLOW-THRU CHILLER
COMPRESSOR
EVAPORATOR
(FALLING FILM)
DISCHARGE
PRE-ROTATION
VANES
SUCTION
BAFFLE
SUB-COOLER
CONDENSER
SUCTION
LIQUID COOLING
FOR MOTOR STATOR
ISOLATION
VALVE
ROTOR COOLING
GAS VENT
(GAS PATH REV A
COMPRESSORS ONLY)
ISOLATION
VALVE
DISCHARGE
CHECK VALVE
LIQUID LEVEL
VALVE
HOT GAS
BYPASS VALVE
LD00924
