York OPTIVIEW - FIGURE 59 - Sample Printout (Schedule); FIGURE 60 - Sample Printout (Sales Order)

JOHNSON CONTROLS
154
FORM 160.78-O2
ISSUE DATE: 5/22/2017
SECTION 4 - PRINTERS
FIGURE 60 - SAMPLE PRINTOUT (SALES ORDER)
YORK SALES ORDER
YMC2 ¬CHILLER ID 1
(c) 2010 Johnson Controls
Mon 01 Nov 2010 9:25:18 AM
Order Information
-----------------------------------------------------
Commissioning Date =
Job Name = York Building 36
Chiller 1
System Model = YMC2xxxxxx
York Order Number
Unit Serial Number
Compressor Model
Evaporator Model
Condenser Model
VSD Model
Nameplate Information
-----------------------------------------------------
Capacity (Tons)
Refrigerant
Refrig Weight (lbs)
RPM
Input kW
Voltage
Phases
Frequency
Input Job FLA
Min Circuit Ampacity
Design Conditions - Evaporator
-----------------------------------------------------
Pressure Drop (ft)
Flow (GPM)
Leaving Temperature (°F)
Entering Temperature (°F)
Fouling Factor
Liquid Type
Brine Percent
Design Conditions - Condenser
-----------------------------------------------------
Pressure Drop (ft)
Flow (GPM)
Leaving Temperature (°F)
Entering Temperature (°F)
Fouling Factor
Liquid Type
Brine Percent
Sales Order Setup
-----------------------------------------------------
-----
Finish Panel Setup = No
FIGURE 59 - SAMPLE PRINTOUT (SCHEDULE)
YORK SCHEDULE
CHILLER ID 3
© 1997 - 1999 YORK INTERNATIONAL CORPORATION
MON 29 MAR 1999 1 27 PM
SCHEDULE = OFF
STANDARD SCHEDULE
---------------------------------------------------------------------------------
SUN START = OFF STOP = OFF
MON START = 8:00 AM STOP = 5:00 PM
TUE START = 8:00 AM STOP = 5:00 PM
WED START = 8:00 AM STOP = 5:00 PM
THU START = 8:00 AM STOP = 5:00 PM
FRI START = 8:00 AM STOP = 5:00 PM
SAT START = OFF STOP = OFF
EXCEPTION DAYS
---------------------------------------------------------------------------------
02 APR 1999 START = OFF STOP = OFF
13 APR 1999 START = 8:00 AM STOP = 10:00 PM
