York OPTIVIEW - Page 153

JOHNSON CONTROLS
153
SECTION 4 - PRINTERS
FORM 160.78-O2
ISSUE DATE: 5/22/2017
4
FIGURE 58 - SAMPLE PRINTOUT (SETPOINTS)
(CONT'D)
Variable Speed Drive
-----------------------------------------------------
Local Input Current Limit = 100 %
Remote ISN Input Current Limit = 30 %
Remote Analog Input Current Limit = 100 %
Remote Digital Input Current Limit = 100 %
Remote Modem Input Current Limit = 100 %
Pulldown Demand Limit = 100 %
Pulldown Demand Time = 0 Min
Input Job Full Load Amps = 185 A
Rated Motor Voltage = 507V
Maximum Motor Current = 505 A
Output Current Rating = 525 A
Stator Resistance = 90
Stator Inductance = 6
Rotor Resistance = 90
Rotor Inductance = 0
Magnetizing Inductance = 0
Poles = 2
Motor Back-EMF Constant = 3276
Motor Power Factor = 0
DC Bus Voltage Setpoint = 750 V
Operation Mode = Voltage
Soft Shutdown Frequency = 50.00 Hz
Flux Command = 0
Current Kp = 0
Current Ki = 0
Current Anti-Windup = 0
Flux Kp = 0
Flux Ki = 0
Flux Anti-Windup = 0
Speed Kp = 0
Speed Ki = 0
Speed Anti-Windup = 0
SW Fault Mask 1 = 0
SW Fault Mask 2 = 0
SW Fault Mask 3 = 0
Motor Monitoring
-----------------------------------------------------
Motor Temperature 1 = Enabled
Motor Temperature 2 = Enabled
Motor Temperature 3 = Enabled
Motor Temperature 4 = Enabled
Motor Temperature 5 = Enabled
Motor Temperature 6 = Enabled
Capacity Control
-----------------------------------------------------
VSD Start Frequency = 172.70 Hz
VSD Soft Shutdown Ramp Rate = 20 Hz/Sec
PRV Start Position = 30.0 %
PRV Shutdown Position = 10.0 %
HGBP Start Position = 0.0 %
LCHLT Setpoint Ramp Rate = 0.1 ~F/S
LCHLT Setpoint Start Offset = 10.0 ~F
Temperature Control Kp = 5.0
Temperature Control Ti = 25.0
Temperature Control Td = 0.0
Temperature Control Max Loading Delta = 1.0
Temperature Control Max Unloading Delta = 1.0
VSD Output Gain = 0.5
VGD Output Gain = 1.0 (Gas
Path B)
PRV Output Gain = 1.0 (Gas
Path A)
HGBP Output Gain = 1.0
Minimum PRV Position = 5.0% (Gas
Path A)
Min Frequency Multiplier
Min Frequency Offset
Min Freq Rate – HGBP Closed (C.OPT.16.01.213 only)
Min Freq Rate – HGBP Open (C.OPT.16.01.213 only)
Min Freq Rate Maximum – 10.00 Hx/Sec (C.OPT.16.02.213
and later)
Min Freq Rate Minimum – 0.10 Hx/Sec (C.OPT.16.02.213
and later)
Min Frequency Admin Multiplier
Min Frequency Mid Position = 40.0 %
Min Frequency Coefcient a1 = 1.440
Min Frequency Coefcient a2 = 1.315
Min Frequency Coefcient a3 = 1.305
Min Frequency Coefcient b1 = 0.525
Min Frequency Coefcient b2 = 0.497
Min Frequency Coefcient b3 = 0.495
Transient Time Delay = 2.5
Transient Deadb Band = 0.010
Transient Max Change = 0.25
Max VGD Knee PRV = 5.0% (Gas
Path A)
Max VGD Knee VGD = 5.0% (Gas
Path A)
Max VGD Coefcient A = 5.0 (Gas
Path A)
Max VGD Coefcient B = 5.0 (Gas
Path A)
Evaporator Pressure Load Limit Threshold
Evaporator Pressure Load Limit Delta
Evaporator Pressure Max Override Threshold
Evaporator Pressure Max Override Delta
Condenser Pressure Load Limit Threshold
Condenser Pressure Load Limit Delta
Condenser Pressure Max Override Threshold
Condenser Pressure Max Override Delta
Input Current Load Limit Threshold
Input Current Load Limit Delta
Input Current Max Override Threshold
Input Current Max Override Delta
Motor Current Load Limit Threshold
Motor Current Load Limit Delta
Motor Current Override Threshold
Motor Current Max Override Threshold
Motor Current Max Override Delta
LCHLT Max Override Delta
FIGURE 58 - SAMPLE PRINTOUT (SETPOINTS)
(CONT'D)
