SECTION 3 - VSD OPERATION

FIGURE 52 - LEFT SIDE OF HYP0490A DRIVE CABINET

LD22393

Cooling

Fans

Line Voltage

Isolation Board

Circuit

Breaker or

Disconnect

Switch

Input Power

Fuses

Voltage

Transient

Board

Supply

Contactor

Precharge

Contactor
