York OPTIVIEW - FIGURE 58 - Sample Printout (Setpoints)

JOHNSON CONTROLS
152
FORM 160.78-O2
ISSUE DATE: 5/22/2017
SECTION 4 - PRINTERS
FIGURE 58 - SAMPLE PRINTOUT (SETPOINTS)
YORK SETPOINTS
SAMPLE CHILLER
YMC2-S-0703AA
SGWM-100000
YMC2 Chiller ID 1
(c) 2010 Johnson Controls
Tue 28 Jun 2011 7:59:24 AM
Software Versions
------------------------------------------------------
Controls =
C.OPT.16.01.307
CC = 3.05
BIOS = C.OPT.00.02
Kernel = 1.21
GP = 1.09
GUI = 0.44
SIO = 1.25
GPIC = 0.13.e.8
Ext I/O = C.EXP.01.00
VSD Inverter =
C.HYP.04.01.02
VSD Rectier =
C.HYP.03.01.02
VSD Modbus = 04.01
System Information
------------------------------------------------------
Data Display Mode = English
System Language = English
Date Format = DD MMM YYYY
Control Source = ISN
Remote Analog Input Range = 0-10 Volts
Line Voltage = 460V
Line Frequency = 60Hz
Chilled Liquid Pump Operation = Standard
Head Pressure Control = Disabled
Hot Gas Bypass = Enabled
Flow Switch Input = J14
Power Failure Restart = Auto
Clock = Enabled
Jumper Settings
-----------------------------------------------------
Liquid Type = Water
Refrigerant Selection = R134a
Printer Setup
-----------------------------------------------------
Automatic Printer Logging = Disabled
Log Start Time = 12:00 AM
Output Interval = 60 Min
Printer Type = Okidata
Baud = 9600 Baud
Data Bits = 8 Bits
Parity = None
Stop Bits = 1 Bit
COM 2 Setup
------------------------------------------------------
Baud = 38400 Baud
Data Bits = 8 Bits
Parity = None
Stop Bits = 2 Bits
Evaporator
-----------------------------------------------------
Leaving Chilled Local Setpoint = 42.0 ~F
Leaving Chilled ISN Setpoint = 42.0 ~F
Leaving Chilled Modem Setpoint = 45.0 ~F
Leaving Chilled Analog Setpoint = 42.0 ~F
Leaving Chilled Digital Setpoint = 42.0 ~F
Remote Range = 10.0 ~F
Restart Offset = 2.0 ~F
Restart Temperature = 44.0 ~F
Shutdown Offset = 4.0 ~F
Shutdown Temperature = 38.0 ~F
Brine Low Evaporator Cutout = 25.0 PSIG
Smart Freeze = Off
Refrigerant = Enabled
Condenser
-----------------------------------------------------
High Pressure Warning Threshold = 162.5 PSIG
Head Pressure Setpoint = 23.0 PSIG
(when HPC is Enable)
Type = 0-10V
(when HPC is Enable)
PID Output = Direct
(when HPC is Enable)
Surge
-----------------------------------------------------
Surge Sensitivity = 0.3
Shutdown = Enabled
Count Limit = 15
Count Window = 3 Min
Refrigerant Level Control
-----------------------------------------------------
Refrigerant Level Setpoint = 50.0 %
Startup Position = 45.0 %
Startup Delay = 0 Min
Ramp Time = 1 Min
Zone Transition Delta = 5.0 %
Zone Transition Time = 10 Sec
Level Control Zone 1 Proportional = 0.50
Level Control Zone 1 Integral = 1.00
Level Control Zone 1 Derivative = 0.00
Level Control Zone 2 Proportional = 0.70
Level Control Zone 2 Integral = 2.50
Level Control Zone 2 Derivative = 0.00
Variable Geometry Diffuser
-----------------------------------------------------
PRV VGD Inhibit = 100 %
PRV Offset = 3 %
Surge React Time = 5 Sec
Surge Wait Time = 0.5 Min
Probe Wait Time = 0.5 Min
Open Pulse = 5 Sec
High Limit = 0.50 V
Low Limit = 0.45 V
Broadband Threshold = 0.18 V
100% VGD Voltage = 3.21 V
0% VGD Voltage = 2.03 V
VGD Calibrated = True
FIGURE 58 - SAMPLE PRINTOUT (SETPOINTS)
(CONT'D)
