Table 19: Pump kit 0035SS/DS, 460 V and 575 V
Isolator AVM location coordinates (X, Y) mm, in.
RRR1 LLL1 RRR2 LLL2
X Distance mm 219 219 1,079 1,079
Y Distance mm 31 969 31 969
X Distance in. 8.62 8.62 42.48 42.48
Y Distance in. 1.22 38.15 1.22 38.15
Table 20: Pump kit 0070SS/DS, 460 V and 575 V
Isolator AVM location coordinates (X, Y) mm, in.
RRR1 LLL1 RRR2 LLL2
X Distance mm 270 270 1,390 1,390
Y Distance mm 31 1,169 31 1,169
X Distance in. 10.63 10.63 54.72 54.72
Y Distance in. 1.22 46.02 1.22 46.02
Table 21: Pump kit 0105SS/DS, 460 V and 575 V
Isolator AVM location coordinates (X, Y) mm, in.
RRR1 LLL1 RRR2 LLL2
X Distance mm 239 239 1,809 1,809
Y Distance mm 31 1,369 31 1,369
X Distance in. 9.41 9.41 71.22 71.22
Y Distance in. 1.22 53.90 1.22 53.90
99YMAE Air-Cooled Inverter Scroll Chiller and Heat Pump
