Zapi ACE3 User Manual

AFFZP0BB – ACE3 – User Manual Page – 49/139
SET OPTIONS
Parameter Allowable range Description
STEERING TYPE
(T, TM)
NONE ÷ ANALOG This parameter defines which type of steering unit is
connected to the controller.
NONE = steering module is not present on the truck; ACE3
does not wait for any CAN message from the EPS and it
does not apply EPS and braking steering cutback.
OPTION#1 = EPS is present and it is configured with
encoder + toggle switches, whose signals are acquired
and related data transmitted to ACE3 via CAN bus.
OPTION#2 = EPS is present and it is configured with
potentiometer + encoder, whose signals are acquired and
related data transmitted to ACE3 via CAN bus.
ANALOG = A hydraulic steering is adopted and ACE3
acquires through one of its analog inputs the signal coming
from a steering potentiometer, as a feedback of the
steering orientation.
M.C. FUNCTION
(T, TM, P, CO)
OFF ÷ OPTION#2 This parameter defines the configuration for the main contactor
or line contactor output (A16, NLC: Negative Line Contactor).
OFF = main contactor is not present. Diagnoses are
masked and MC is not driven.
ON = main contactor is in standalone configuration.
Diagnoses are performed and MC is closed after key-on
only if they have passed.
OPTION#1 = for a traction & pump setup, with only one
main contactor for both controllers. Diagnoses are
performed and MC is closed after key-on only if they have
passed.
OPTION#2 = for a traction & pump setup, with two main
contactors. Each controller drives its own MC. Diagnoses
are performed and MCs are closed after key-on only if they
have passed.
EBRAKE ON APPL.
(T, TM, P, CO)
ABSENT, PRESENT This parameter enables or disables the management of the
electromechanical brake:
ABSENT = the diagnosis are masked and E.B. is not
driven upon a traction request.
PRESENT = E.B. is driven upon a traction request if all the
related diagnosis pass.
AUX OUT FUNCTION
(A)
NONE, BRAKE This parameter enables or disables the output A18 (NEB):
NONE = the diagnosis are masked and E.B. is not driven
upon a traction request.
BRAKE = E.B. is driven upon a traction request if all the
related diagnosis pass. The behavior on a slope depends
on the “STOP ON RAMP” setting (see “Behavior on a
slope” table at the end of the paragraph).
SYNCRO
(CO)
OFF, ON This parameter enables or disables the syncro message.
OFF = the Syncro message is not used.
ON = the Syncro message is enabled.
