AFFZP0BB – ACE3 – User Manual Page – 51/139
SET OPTIONS
Parameter Allowable range Description
EV4
(A – Premium version
only)
ABSENT, DIGITAL This parameter defines how the output B19 (NEV4) operates.
ABSENT = output not enabled, no on B19.
DIGITAL = B19 manages an on/off valve.
EV5
(A – Premium version
only)
ABSENT, DIGITAL This parameter defines how the output B9 (NEV5) operates.
ABSENT = output not enabled, no on B9.
DIGITAL = B9 manages an on/off valve.
HIGH DYNAMIC
(T, TM, P, CO)
OFF, ON This parameter enables or disables the High-Dynamic function.
ON = all acceleration and deceleration profiles set by
dedicated parameters are ignored and the controller works
always with maximum performance.
OFF = standard behavior.
INVERSION MODE
(T, TM)
OFF, ON This parameter defines the behavior of the Quick-Inversion
input A11.
ON = the Quick-Inversion switch is normally closed
(function is active when the switch is open).
OFF = the Quick-Inversion switch is normally open
(function is active when the switch is closed).
STEER TABLE
(TM)
NONE ÷ OPTION#2 This parameter defines the steering table.
NONE = The inverter does not follow any predefined
steering table, but it creates a custom table according to
WHEELBASE MM, FIXED AXLE MM, STEERING AXLE
and REAR POT ON LEFT parameters.
OPTION#1 = Three-wheels predefined steering table.
OPTION#2 = Four-wheels predefined steering table.
The steering table depends on truck geometry. The two
available options by default may not fit the requirements
of your truck. It is advisable to store the dimensions of the
truck in the parameters listed above in order to create a
custom steering table.
It is strongly recommended to consult paragraph 8.7 in
order to properly understand how to fill the mentioned
parameters. If the steering performance of the truck does
not match your requirements even after you have entered
the right truck dimensions, contact a Zapi technician in
order to determine if a custom steering table has to be
created.
WHEELBASE MM
(TM)
0 ÷ 32000 This parameter must be filled with the wheelbase, i.e. the
distance between the two axles of the truck, expressed in
millimeters.
See paragraph 8.7.
FIXED AXLE MM
(TM)
0 ÷ 32000 This parameter must be filled with the axle width at which the
non-steering wheels are connected, expressed in millimeters.
See paragraph 8.7
