AFFZP0BB – ACE3 – User Manual Page – 65/139
TESTER (Master)
Parameter
Unit of measurement
(resolution)
Description
TEMPERATURE
(A)
Celsius degrees (1 °C) Temperature measured on the inverter base plate.
This temperature is used for the HIGH TEMPERATURE
alarm.
MOTOR TEMPERAT.
(A)
Celsius degrees (1 °C) Motor-windings temperature.
Normally the sensor is a PTC Philips KTY84-130. This
temperature is used for the MOTOR OVERTEMP alarm.
A6 TILLER
(T, TM)
OFF/ON Status of the TILLER/SEAT input (A6).
A11 QI/PB
(T, TM)
OFF/ON Status of the Pedal-Brake/Quick-Inversion input (A11)
B13 HS
(T, TM)
OFF/ON Status of the Hard&Soft input (B13).
A4 FW SW
(T, TM, TS)
OFF/ON Status of the forward input (A4).
A4 ENABLE
(T, TM, TS)
OFF/ON Status of the driving-demand input (A4).
A5 BW SW
(T, TM)
OFF/ON Status of the backward input (A5).
B11 AUX3
(T, TM)
OFF/ON Status of the AUX3 input (B11) that enables EV3
B4 AUX1
(T, TM)
OFF/ON Status of the AUX3 input (B4) that enables EV1
B5 AUX2
(T, TM)
OFF/ON Status of the AUX3 input (B5) that enables EV2
A13 SR/HB
(T, TM)
OFF/ON Status of the Speed-Reduction/Hand-Brake input (A13).
B6 FW-INCH
(TS)
OFF/ON Status of the forward-inching input (B6).
B13 L-BW-IN
(TS)
OFF/ON Status of the backward-inching input (B13).
A6 SEAT
(P)
OFF/ON Status of the TILLER/SEAT input (A6).
