TESTER (Master)
Parameter
Unit of measurement
(resolution)
Description
B13 SPD1
(P)
OFF/ON Status of the 1ST-speed input (B13).
A11 HYDRO
(P)
OFF/ON Status of the hydraulic-steering input (A11).
A4 LFT/E
(P)
OFF/ON Status of the lift input (A4).
A5 LOWER
(P)
OFF/ON Status of the lowering input (A5).
B6 SPD2
(P)
OFF/ON Status of the 2ND-speed input (B6).
B4 SPD3
(P)
OFF/ON Status of the 3RD-speed input (B4).
B5 SPD4
(P)
OFF/ON Status of the 4TH-speed input (B5).
B11 SPD5
(P)
OFF/ON Status of the 5TH-speed input (B11).
A13 CUTBAC1
(P)
OFF/ON Status of the speed-reduction input (A13).
NODE ID
(CO)
0 ÷ 56 Node ID setting for CAN OPEN Protocol
TARGET SPEED
(CO)
10 Hertz (1 daHz)
This value shows the speed setpoint transmitted over
CAN OPEN protocol. It is expressed in tenths of Hz.
BRAKING REQUEST
(CO)
0 ÷ 255 This value shows the braking setpoint transmitted over
CAN OPEN protocol.
CONTROL WORD
(CO)
0 ÷ 65535 It shows the Control Word transmitted upon CAN OPEN
protocol.
STATUS WORD
(CO)
0 ÷ 65535 It shows the Status Word travelling upon CAN OPEN
protocol.
WARNING SYSTEM
(CO)
0 ÷ 65535 In case of warning it shows the related warning code.
TARGET EVP1
(CO)
Percentage (1%) This value shows the setpoint of proportional
electrovalve EVP1 in CAN Open configuration.
