Zapi ACE3 User Manual

AFFZP0BB – ACE3 – User Manual Page – 67/139
TESTER (Master)
Parameter
Unit of measurement
(resolution)
Description
TORQUE REQ.
(CO)
Newton Meter (1 Nm) This value shows the torque setpoint for AC motor in
CAN Open configuration.
TORQUE BRK REQ.
(CO)
Newton Meter (1 Nm) This value shows the torque setpoint during braking for
AC motor in CAN Open configuration.
A3 POT#1
(A)
Volt (0.01V) Voltage of the analog signal on A3.
A10 POT#2
(A)
Volt (0.01V) Voltage of the analog signal on A10.
B2 POT#3
(A)
Volt (0.01V) Voltage of the analog signal on B2.
B10 POT#4
(A)
Volt (0.01V) Voltage of the analog signal on B10.
B3 POT#5
(A)
Volt (0.01V) Voltage of the analog signal on B3.
SIN FB. INPUT
(A – Only for BLE3 with
sin/cos sensor)
Volt (0.01 V) Voltage of sine input (B7).
COS FB. INPUT
(A – Only for BLE3 with
sin/cos sensor)
Volt (0.01 V) Voltage of cosine input (B14).
A19 SET EVP
(A)
Percentage (1%) This value shows the setpoint of proportional
electrovalve EVP.
B16 OUTPUT EV1
(A – Only Premium
version)
OFF/ON It shows the status of the EV1 output (B16).
B17 OUTPUT EV2
(A – Only Premium
version)
OFF/ON It shows the status of the EV2 output (B17).
B18 OUTPUT EV3
(A – Only Premium
version)
OFF/ON It shows the status of the EV3 output (B18).
B19 OUTPUT EV4
(A – Only Premium
version)
OFF/ON It shows the status of the EV4 output (B19).
